Product
JSA E-Rickshaw King
We have been able to manufacture, export and supply our clients a qualitative range of three wheelers that is a common means of public transportation in many countries. It is a usually three-wheeled cabin cycle for private use and as a vehicle for hire.
Motor Output
1150W brushless motor, 25 km/h speed.
1150W brushless motor, 25 km/h speed.
Torque Delivery
Differential transmission ensures smooth rides.
Differential transmission ensures smooth rides.
Spacious Seating
4+1 seats with smooth suspension.
4+1 seats with smooth suspension.
Rider Comfort
Cushioned seats, protective metal roof
Cushioned seats, protective metal roof
Battery Options
130Ah, 150Ah, and lithium choices.
130Ah, 150Ah, and lithium choices.
Quick Charging
8-hour charge via 220V outlet.
8-hour charge via 220V outlet.
Brake Control
Drum brakes with strong chassis design.
Drum brakes with strong chassis design.
Ride Stability
2030 mm wheelbase ensures balance.
2030 mm wheelbase ensures balance.
Power System
Supports lithium and lead-acid batteries.
Supports lithium and lead-acid batteries.
Efficient Drive
Low-cost, energy-saving drivetrain.
Low-cost, energy-saving drivetrain.
Modern Build
Sleek frame with durable wheel rims.
Sleek frame with durable wheel rims.
Technical
Specifications
-
Performance
-
Brake
-
Dimension
-
Tyres
-
Electricals
| Motor | 48V 1150W |
| Motor Capacity | 3.5 Nm |
| Battery Capacity | 6.24kWh / 6.48kWh / 7.2kWh |
| Battery Make | EASTMAN / LIV GUARD |
| Mileage | 100 - 130 Kms |
| Maximum Speed | 25 Kmph |
| Transmission Type | Differential |
| Charger | 48V 16 Amp / 48V 18 Amp |
| Brake Type | Mechanical Drum Type |
| Wheel Base | 2030 mm |
| Overall Length | 2740 mm |
| Overall Width | 998 mm |
| Overall Height | 1740 mm |
| Roof Body | Steel |
| Seating Capacity | 4+1 |
| Front Suspension | Telescopic Shock Absorber |
| Rear Suspension | Leaf Spring with Shock Absorber |
| Motor | 48V 1150W |
| Motor Capacity | 3.5 Nm |
| Battery | 130Ah / 135Ah / 150Ah |
| Battery Capacity | 6.24kWh / 6.48kWh / 7.2kWh |
| Battery Make | EASTMAN / LIV GUARD |
| Charger | 48V 16 Amp / 48V 18 Amp |
